Custom ratchets and jaw clutches
Commercial Gear & Sprocket manufactures custom ratchets and jaw clutches for OEMs, machine builders, replacement applications and industrial equipment — combining dedicated ratchet and clutch cutting equipment, CNC machining, secondary operations and inspection.
Ratchets and jaw clutches made to your specifications
Ratchets and jaw clutches are specialized mechanical components for equipment that needs controlled engagement, indexing, holding or torque transmission.
We manufacture custom ratchets and jaw clutches to your drawings, component geometry, dimensions, material, bore configuration, tolerances and quantity — with involute gear milling, ratchet cutting and clutch cutting among our specialized capabilities.
Ratchet and jaw clutch size range
Ratchet diameter
Up to 30″
Custom ratchets manufactured up to 30 inches in diameter.
Jaw clutch diameter
Up to 24″
Custom jaw clutches manufactured up to 24 inches in diameter.
Additional machining
As required
Bores, shafts, keyways and holes to the part requirements.
Product type
Custom ratchets & jaw clutches
Manufacturing
To your requirements
Tooth profile, number of teeth or jaws, bore configuration, shaft features, material, heat treatment, finish, tolerances, mating components and inspection should be shown on your drawing or reviewed during quotation.
How we manufacture ratchets and jaw clutches
Dedicated ratchet and clutch cutting machinery with CNC machining, secondary operations, finishing and inspection — chosen around geometry, tooth or jaw form, diameter, material, quantity and the mating part.
Whiton #1 and Whiton #2 machines cut ratchet teeth and involute gear forms, for ratchets up to 30″ diameter.
Whiton equipment with face gear attachments cuts custom jaw clutches up to 24″ diameter to your jaw configuration.
CNC turning centers with live tooling and 4-axis vertical machining for bores, shafts, keyways and holes.
Chamfering, automatic deburring, heat treatment coordination, metal finishing and inspection.
Dedicated cutting equipment
Ratchet teeth and clutch jaws need specialized cutting. Our Whiton machines are set up specifically for involute gear milling, ratchet cutting and clutch cutting, with face gear attachments for jaw forms.
Ratchet cutting & involute milling
Ratchet & clutch cutting
Jaw clutch & face tooth forms
Ratchet and clutch design
A ratchet lets motion pass one way and locks it the other; a jaw clutch engages or disengages a drive through interlocking jaws. Both rely on tooth or jaw geometry that suits the mating part exactly.
What we confirm from your drawing:
Profile angle, number of teeth or jaws and tooth-top flat.
Teeth on-center or off-center relative to the bore.
The pawl or mating clutch half the part engages.
Bore, keyway and shaft features for the assembly.
CNC machining
Machining before or after the teeth or jaws are cut, in the same job.
Diameters, faces and hubs turned to size.
Milled features produced to the drawing.
Bores machined for the required fit.
Shafts machined and bores opened up as needed.
Keyways cut to your specification.
Holes and other customer-specified features.
Finishing & secondary operations
Dedicated chamfering and automatic deburring equipment, plus outside sources for heat treatment and metal finishing.
Tooth and jaw edges chamfered after cutting.
Burrs removed from teeth, jaws and machined features.
Specified heat treatment sourced and coordinated.
Finishes applied as your drawing requires.
Critical dimensions verified to the drawing.
Tooth form checked on an optical comparator.
Prototype to production
Prototype ratchets and clutches for new designs.
Replacement ratchets and jaw clutches for existing equipment.
Components made to your existing drawings, from your blanks or ours.
Short runs through production-volume OEM orders.
Ratchets and jaw clutches for industrial equipment
Custom ratchets and jaw clutches are used in machinery where component geometry and engagement must match a specific mechanical application. Send the drawing, mating-part information, material, quantity and operating requirements with your quote request.
Ratchets that lock motion in one direction.
Controlled step-by-step indexing.
Jaw clutches for positive drive engagement.
Interlocking jaws that carry drive torque.
Industries we serve
Ratchets and jaw clutches for construction machinery.
Custom ratchets and clutches for defense equipment.
Precision ratchets for medical equipment.
Components built to OEM drawings.
Indexing ratchets and clutches for machine tools.
Heavy-duty ratchets and clutches for mining.
Ratchet and clutch components for transit equipment.
Components for rail cars and track equipment.
Compact ratchets and clutches for power tools.
Ratchet and jaw clutch quality inspection
We use documented inspection procedures and calibrated measuring equipment, with specific procedures for ratchets. Jaw clutch inspection is planned around your drawing, mating components and purchase order in a job-specific quality plan.
Runout checked with a pin in the teeth.
Profile angles inspected on an optical comparator.
Flat on top of the tooth checked when specified.
On-center or off-center position verified when required.
Jaw form and dimensions checked to your drawing.
Fit with the pawl or mating clutch half.
Bore size and keyway verified.
Plan tailored to your part, drawing and purchase order.
How it works
01
Drawing or CAD file, diameter, tooth or jaw geometry, mating part, material and quantity.
02
We plan the cutting, machining, secondary operations and inspection for the part.
03
Teeth or jaws cut on Whiton equipment, machined, finished and inspected before shipping.
Custom ratchet and jaw clutch manufacturer since 1946
Specialized ratchet and clutch cutting equipment with CNC machining, secondary operations, inspection and decades of manufacturing experience.
Whiton machines for involute gear milling, ratchet cutting and clutch cutting.
Dedicated size capability for both ratchets and jaw clutches.
Turning, milling, bores, shafts, keyways, chamfering and finishing.
Single prototypes, replacements, short runs and long-run orders.
Runout, profile angle, tooth-top width and tooth position checks.
Custom ratchet and jaw clutch quotes
Send us your drawing, specifications, quantity and application. We will review the component and plan the right cutting, machining, secondary operations and inspection.
Ratchet and jaw clutch FAQ
Yes. We manufacture custom ratchets and jaw clutches to your drawings, dimensions, tooth or jaw geometry, material, tolerances and application requirements.
We manufacture custom ratchets up to 30 inches in diameter.
We manufacture custom jaw clutches up to 24 inches in diameter.
We use specialized Whiton equipment for involute gear milling, ratchet cutting and clutch cutting, supported by CNC machining, chamfering, deburring, heat treatment coordination, metal finishing and inspection.
Yes. Our CNC turning and milling covers bores, shafts, keyways, drilled and tapped holes and other features on your drawing.
Yes. We support single prototypes, replacement parts, short runs and long-run production orders.
Our ratchet procedure covers runout with a pin in the teeth, tooth-profile angle on an optical comparator, the flat on top of the tooth where specified, and tooth position relative to the bore.
A drawing or CAD file, diameter, tooth or jaw geometry, bore or shaft requirements, mating-part information, material, quantity, tolerances, secondary processes, inspection and delivery timeline.
