Custom timing belt pulley manufacturing
Commercial Gear & Sprocket manufactures custom timing belt pulleys and gear belt pulleys for OEMs, machine builders, replacement applications and industrial equipment — in multiple tooth profiles, custom belt widths and customer-specific configurations.
Timing pulleys made to your specifications
Timing and gear belt pulleys use a defined tooth profile that engages a matching toothed belt. Profile, pitch, width, bore and every other dimension must suit the belt and the machine.
We manufacture custom timing pulleys to your drawings, dimensions, tooth profile, pitch, belt width, bore configuration, material and quantity — trapezoidal, metric curvilinear, Gates PowerGrip®, Goodyear Super Torque Pd®, metric T and AT, 40 DP and zero-backlash pulleys, all in custom belt widths.
Timing pulley sizes, pitches and tooth profiles
Maximum diameter
Up to 36″
Timing and gear belt pulleys up to 36 inches in diameter.
Maximum face width
Up to 36″
Face widths up to 36 inches.
Pitch range
⅛″ – 1¼″
Pulley pitch from ⅛ inch through 1¼ inches.
Belt width
Custom widths available
Manufacturing
To your requirements
Bore size, hubs, keyways, mounting holes, material, tolerances, finishing and inspection should be shown on your drawing or reviewed during quotation.
How we manufacture custom timing pulleys
Custom pulley manufacturing with CNC machining, secondary operations and customer-specific finishing — the approach depends on tooth form, pitch, diameter, face width, bore, material and quantity.
Trapezoidal, HTD®, PowerGrip®, Super Torque Pd®, metric T and AT, 40 DP and zero-backlash — specify the pulley around your belt system.
Every listed profile can be made in any custom belt width — ideal for replacements and non-standard drives.
CNC lathes with live tooling and sub-spindles plus a 4-axis CNC vertical mill for bores, hubs, keyways and holes.
Deburring, finishing, heat treatment and metal finishing through outside sources, and inspection.
Custom belt widths
Because our pulley profiles can be made in any custom belt width, we can match an existing belt-drive system, OEM machine or specialized equipment rather than forcing a standard width. Supply the exact width and mating belt with your drawing.
Any width for listed profiles
Available on request
Bores, hubs, keyways, holes
Timing pulley tooth profiles
A timing pulley has to match its belt exactly. We support a wide range of tooth forms so you can specify the pulley around your belt system instead of redesigning the drive.
Available tooth forms:
MXL (.080″), XL (.200″), L (.375″), H (.500″).
HTD® 3M, 5M, 8M · Gates PowerGrip® GT 2, 3, 5, 8MM.
Goodyear STPD 3M, 5M, 8M · metric T2, T2.5, T5, T10, T20.
AT5, AT10, AT20 · 40 DP (.0816″) · zero backlash.
CNC machining
Pulley features machined on CNC lathes with live tooling and sub-spindles and a 4-axis CNC vertical mill.
Bores machined to size and tolerance.
Hubs machined to your configuration.
Keyways cut to your specification.
Set-screw and mounting holes.
Shaft features machined to the drawing.
Other customer-specified dimensions and features.
Finishing & secondary operations
Dedicated deburring and finishing equipment, plus outside sources for heat treatment and metal finishing.
Burrs removed from teeth and machined features.
Pulleys finished ready to install.
Extra features added in the same job.
Heat treatment through trusted outside sources.
Finishes through trusted outside sources.
Checked to your project requirements.
Prototype to production
Single pulleys for new machine designs.
Timing pulleys reproduced for existing drives.
Custom tooth profiles and belt widths.
Short runs through production-volume OEM orders.
Timing pulleys for industrial equipment
Custom timing pulleys are used wherever a pulley must match a specific toothed belt, dimensional configuration and operating requirement. Send the tooth profile, pitch, belt width, diameter, bore and material with your quote request.
Positive, no-slip timing between shafts.
Zero-backlash pulleys for accurate motion.
Custom pulleys built to OEM drawings.
Pulleys matched to existing belt systems.
Industries we serve
Custom timing pulleys built to OEM drawings.
Precision pulleys for machine tool drives.
Belt-drive pulleys for construction machinery.
Heavy-duty pulleys for mining equipment.
Including a custom timing pulley for a power-tool application.
Fine-pitch pulleys for medical equipment.
Custom pulleys for defense suppliers.
Belt-drive components for transit equipment.
Pulleys for rail cars and track equipment.
Timing pulley quality and inspection
Every new job gets a quality plan built around your part, drawing and purchase order. For timing pulleys the inspection characteristics are defined by your drawing — these are the requirements to identify when you request a quote.
The belt tooth form the pulley must match.
Pulley pitch from ⅛″ to 1¼″.
Tooth count for the required ratio.
Face width and custom belt width.
Bore size and hub configuration.
Keyways, set screws and mounting holes.
Tolerances shown on your drawing.
Any specific checks your drawing or PO requires.
How it works
01
Drawing, tooth profile, belt type, pitch, teeth, widths, bore and quantity.
02
We confirm the profile, pitch, belt width and machining features for your drive.
03
Your pulleys are cut, machined, finished and inspected to the quality plan.
Custom timing pulley manufacturer since 1946
A broad range of tooth forms, custom belt widths, CNC machining, flexible production and decades of industrial manufacturing experience.
Trapezoidal, HTD®, PowerGrip®, Super Torque Pd®, T, AT, 40 DP and zero backlash.
Pulleys up to 36″ diameter × 36″ face, ⅛″ to 1¼″ pitch.
Listed profiles in custom widths, with CNC machining for your features.
Single prototypes, replacements, short runs and long-run orders.
Third-generation and family-owned, serving OEMs and industry since 1946.
Custom timing pulley quotes
Send us your drawing, belt information, pulley dimensions, quantity and application. We will review the tooth profile, pitch, custom belt width, machining features and production requirements.
Timing belt pulley FAQ
Yes. We manufacture custom timing and gear belt pulleys to your dimensions, tooth profile, pitch, belt width, bore configuration, material, quantity and application.
Timing belt pulleys up to 36 inches in diameter with face widths up to 36 inches.
Our timing belt pulleys range from ⅛ inch through 1¼ inch pitch.
Trapezoidal MXL, XL, L and H; HTD® 3M, 5M and 8M; Gates PowerGrip® 2MM, 3MM, 5MM and 8MM; Goodyear Super Torque Pd® 3M, 5M and 8M; metric T and AT profiles; 40 DP; and zero-backlash pulleys.
Yes. Every listed tooth form can be manufactured in the belt width you need.
Yes. Our CNC turning and milling covers bores, hubs, keyways, holes and other features — define them on your drawing.
Yes. We support single prototypes, short runs and long-run production orders for replacement, prototype and production pulleys.
A drawing or CAD file, tooth profile, belt type, pitch, teeth, belt and face width, bore, hub, material, quantity, tolerances, secondary operations, inspection and delivery timeline.
